Leg Options | Model |
No rails | SY |
H-type legs | HSY |
C-type legs | CSY |
Model Number | Drainboard | O.A.Dims – in. | Bowl Dims – in. | Qty/ Pallet | CBM | |||||
L | W | H | DB | A | B | C | ||||
JSA2-201612N | NO | 38 | 26 | 45 | 0 | 16 | 20 | 12 | 6 | 0.248 |
JSA2-201612L-18 | Left | 53 | 26 | 45 | 18 | 16 | 20 | 12 | 6 | 0.344 |
JSA2-201612R-18 | Right | 53 | 26 | 45 | 18 | 16 | 20 | 12 | 6 | 0.344 |
JSA2-201612D-18 | Double | 68 | 26 | 45 | 18 | 16 | 20 | 12 | 6 | 0.438 |
JSA2-181812N | NO | 42 | 24 | 45 | 0 | 18 | 18 | 12 | 6 | 0.253 |
JSA2-181812L-18 | Left | 57 | 24 | 45 | 18 | 18 | 18 | 12 | 6 | 0.342 |
JSA2-181812R-18 | Right | 57 | 24 | 45 | 18 | 18 | 18 | 12 | 6 | 0.342 |
JSA2-181812D-18 | Double | 72 | 24 | 45 | 18 | 18 | 18 | 12 | 6 | 0.431 |
JSA2-241812N | NO | 42 | 30 | 45 | 0 | 18 | 24 | 12 | 6 | 0.314 |
JSA2-241812L-18 | Left | 57 | 30 | 45 | 18 | 18 | 24 | 12 | 6 | 0.425 |
JSA2-241812R-18 | Right | 57 | 30 | 45 | 18 | 18 | 24 | 12 | 6 | 0.425 |
JSA2-241812D-18 | Double | 72 | 30 | 45 | 18 | 18 | 24 | 12 | 6 | 0.535 |
JSA2-241812L-24 | Left | 63 | 30 | 45 | 24 | 18 | 24 | 12 | 6 | 0.461 |
JSA2-241812R-24 | Right | 63 | 30 | 45 | 24 | 18 | 24 | 12 | 6 | 0.461 |
JSA2-241812D-24 | Double | 84 | 30 | 45 | 24 | 18 | 24 | 12 | 6 | 0.623 |
JSA2-202012N | NO | 46 | 26 | 45 | 0 | 20 | 20 | 12 | 6 | 0.299 |
JSA2-202012L-20 | Left | 63 | 26 | 45 | 20 | 20 | 20 | 12 | 6 | 0.408 |
JSA2-202012R-20 | Right | 63 | 26 | 45 | 20 | 20 | 20 | 12 | 6 | 0.408 |
JSA2-202012D-20 | Double | 80 | 26 | 45 | 20 | 20 | 20 | 12 | 6 | 0.517 |
JSA2-242412N | NO | 54 | 30 | 45 | 0 | 24 | 24 | 12 | 6 | 0.403 |
JSA2-242412L-24 | Left | 75 | 30 | 45 | 24 | 24 | 24 | 12 | 6 | 0.557 |
JSA2-242412R-24 | Right | 75 | 30 | 45 | 24 | 24 | 24 | 12 | 6 | 0.557 |
JSA2-242412D-24 | Double | 96 | 30 | 45 | 24 | 24 | 24 | 12 | 6 | 0.711 |
